pulsor 400MT

BENEFITS

Refrigeration Capacity
(System net cooling capacity under A.T.P. Conditions at 30°C ambient)

MCL 850MCV 850MCS 600

Nominal capacity (-20°C/30°C) (W)1 930/1 930/1 930

Capacity on road at 2400rpm 0°C (W)
3 115/2 810/2 525

Capacity on road at 2400rpm -20°C (W)
1 785/1 560/1 260

Capacity on road at 1000rpm 0°C (W)
3 115/2 810/2 525

Capacity on road at 1000rpm -20°C (W)
1 785/1 560/1 260

Standby capacity* (W)
3 160/2 780/2 580

Standby capacity** (W)
1 805/1 570/1 275

Heating Capacity

Heating system (W)
2 100/2 100/1 500

Standby (W)
2 1002 1001 500

Airflow
(High speed engine operation)

(AMCA 21085) m3/hr1 0301 015695

Weight

Road and standby condenser91 kg

Evaporator MCL85022 kg

Evaporator MCV85019 kg

Evaporator MCS60017 kg

Compressor

ModelBS330/MS330

Displacement32,7 cm3

n° of cylinders

Electrical Stand by Motor

Voltage / Phase / Frequency230/1/50-60 Hz
400/3/50-60 Hz

RatingDepending on configuration

Refrigerant

TypeR-404A

ChargeDepending on configuration

Sound Pressure

High speed57 dBA

Unit

Condenser dimensions (D x W x H)577 x 1124 x 235 mm

*Stand by capacities are linked to voltage version (400 VAC or 230 VAC)

**Stand by capacities are given for 400 VAC version
